13.8Vdc Switch Mode Power Supply 43.5A
Code: MX650764
£64.28
(£53.57
ex VAT)
Quantity Pricing
2
-
3
£63.80
each
(£53.17
each ex VAT)
4
+
£57.72
each
(£48.10
each ex VAT)
-
VAT
Choose quantity
Order now for next working day dispatch.
Description
Series of 13.8Vdc switching power supplies, suitable for applications that require a stable and regulated DC voltage output.
The specific voltage of 13.8V is commonly used because it aligns with the nominal voltage of a 12V lead-acid battery when it is fully charged.
This makes these power supplies compatible with systems that are normally battery-powered allows them to provide a stable power source even when the battery voltage fluctuates.
Ideal use for radio equipment, security systems, alarm systems, access control systems, 12Vdc LED Lighting systems and central monitoring systems.
For indoor use only.
- Short circuit protection
- Overload protection
- Auto reset
- Easy installation, screw terminals
- Fan cooling for higher power models
- Higher power models with 3 channels to spread load
- Power Supply: 240 Vac / 6A, 50Hz
- Power: max 600.3W
- Output current 43.5A
- Output channels 3
- Output voltage13.8Vdc
- IP rating IP20
- Voltage range 12.42V-15.18V
- Working temperature -10~40 deg Celsius
- Dimensions 240 x 65 x 125mm
- Weight 1.15kg
mercury product code: 650.764UK
