QX10A active speaker cabinet
Code: MX178753
-
VAT
Out of Stock
Please enter your email address below and we will notify you once this item is back in stock.
Description
Active PA speaker units in a contemporary styled moulded ABS cabinet with integral carry handle and a constant directivity horn. The built-in mixer amplifier section delivers high output to the driver units to develop high SPLs.
- Built-in amplifier with mixer section
- Lightweight ported cabinet
- Titanium compression driver
- Mic/line inputs with volume controls
- Tone controls
- 35mmØ internal top hat
QTX product code: 178.753UK
Details
Power supply 230Vac, 50Hz (IEC)
SNR 87dB
THD 0.1%
Dispersion 90° x 60° (H x V)
Impedance 4 Ohms
Inputs Line (XLR, Jack)
Output power: RMS 150W
Output power: Max. 300W
Sensitivity (1m,1W) 97dB
LF driver 250mm (10")
Frequency response 48Hz - 20kHz
Weight 8.0kg
Dimensions 320 x 470 x 270mm
HF driver 25mm Ti compression driver
HF driver: Coil size 25mmØ
LF driver: Coil size 52mmØ
Max SPL 121dB
Crossover frequency 4.0kHz
